Metal Turning 316 Stainless Steel Part – SS316 Precision Turned Parts Manufacturer
Welcome to browse our products list, here we are going to show you our 316 stainless steel turning part. The demand for precision-turned metal parts requires efficient and accurate production methods, and metal turning is one of the ways. At Junying CNC machining factory, we are capable of various metal machining operations, especially stainless steel CNC turning, milling, and drilling. We produce precision turned parts with a wide variety of stainless steel alloys, whether you require a single prototype or batch production, you can get the most cost-effective solution here. Our experienced engineers and machinists will carefully match the appropriate technology with your design requirements, and then complete the metal turning process to achieve high-quality standards. We are professional at working with stainless steel materials during the turning process, from cutting tools to cutting speed to other aspects, and every detail will be carefully taken. As a China CNC turned parts manufacturer, Junying is able to supply precision-turned components for wide-ranging industries such as medical, automotive, electronics, marine, food, aerospace, etc.
Mechanical and Physical Properties of 316 Stainless Steel
| Property | 316 Bar and Section (up to 160 mm thick) | 316 Sheet (up to 8 mm thick) | 316 Plate (8 – 75 mm thick) |
|---|---|---|---|
| Tensile Strength (MPa) | 500 – 700 | 530 – 680 | 520 – 670 |
| Proof Stress (MPa) | 200 (Min) | 240 (Min) | 220 (Min) |
| Elongation A50 mm | 40 % (Min) | 40 % (Min) | 45 % (Min) |
| Hardness Brinell | 215 Max HB | ||
| Density (g/cm3) | 8.00 | ||
| Melting Point (°C) | 1400 | ||
| Modulus of Elasticity (GPa) | 193 | ||
| Electrical Resistivity (Ω.m) | 0.74 x 10-6 | ||
| Thermal Conductivity (W/m.K) | 16.3 | ||
| Thermal Expansion (/K) | 15.9 x 10-6 | ||
Industries and Applications of 316 Stainless Steel Parts
Food & Beverage
- Processing equipment
- Storage tanks
- Industrial utensils
Medical & Pharmaceutical
- Surgical instruments
- Medical implants
- Sterilization equipment
- Laboratory apparatus
Marine & Coastal
- Boat fittings
- Offshore structures
- Architectural components (railings, panels, trim)
Chemical & Industrial
- Processing equipment
- Reaction vessels
- Pipes and valves
- Dyeing equipment
Oil & Gas
- Refinery components
- Pipeline parts
- Offshore platform equipment
Construction
- Exterior architectural elements
- Weather-resistant fixtures
- Coastal building components
Advantages of Our 316 Stainless Steel Part Precision Turned Parts
– Economical for low or high-volume production
– High precision and accuracy, dimensional stability
– Efficiency for simple or complex projects
– Different stainless steel varieties
Specifications of 316 Stainless Steel Part Precision Turned Parts
| Material | 316 Stainless steel |
| Tolerance | +/-0.05mm |
| Surface Treatment | Custom |
| Main Process | Turning |
| Quality Control | Strictly Quality control in the whole process, from material to packing, Coordinate-measuring machine |
| Usage | Machine parts |
| Customized Drawings | Auto CAD, JPEG, PDF, STP, IGS, and most other file formats are accepted |
